WC Welded Hydraulic Cylinder: 2 Bore x 24 Stroke, 1.125 Rod

This Chief WC welded clevis hydraulic cylinder, rated at 3000 PSI, features a 2 in. bore x 24 in. stroke and a 1.125 in. rod. Designed for demanding double-acting applications, including agriculture, compact construction, transportation equipment, and waste/recycling, its welded construction provides a rugged, low-profile alternative to conventional tie-rod cylinders. An extended 2 in. base-end clevis provides a greater swing radius for added mounting flexibility.

Built for dependable performance and long service life, Chief WC cylinders combine a precision-honed steel tube, a ductile iron screw-in gland, a ductile iron piston with wear ring, and heavy-duty sealing components. Ductile iron female clevis mounts include pins and clips for convenient installation. Each cylinder is functionally tested and pressurized to 1.5 times normal working pressure to help ensure dependable performance.

• Built for demanding environments: Designed for reliable use in agricultural equipment, compact construction, transportation equipment, waste/recycling systems, and other demanding double-acting applications.
• Low-profile welded design: A ductile iron screw-in gland helps reduce the cylinder profile while maintaining the strength of the welded clevis design.
• Greater mounting flexibility: The extended 2 in. base-end clevis provides a greater swing radius to accommodate a wider range of equipment movement.
• Smooth, precise operation: Precision-honed steel tubing provides a smooth internal surface for consistent cylinder movement and dependable sealing performance.
• Long-lasting piston sealing: A Hallite 755 piston seal with wear ring is designed for prolonged wear resistance and dependable operation.
• Protection against leaks and contaminants: Buna O-ring tube seals, a deep PolyPak B-lip rod seal, and a urethane snap-in rod wiper help retain hydraulic fluid while keeping contaminants out.
• Heavy-duty mounting: Ductile iron female clevis mounts provide a strong connection, with pins and clips included for convenient installation.
• 3-year limited warranty: Backed by a 3-year limited warranty for added confidence in long-term performance.
